Connection diameter: DN15 DN20 DN25 two-way/three-way
Connection method: internal thread G1/2″ G3/4 “G1” (customizable NPT)
Media range: hot and cold water or 30% ethylene glycol solution 2℃~95℃
Valve body pressure: 2. OMpa
Working voltage: AC24V/AC110V/AC220V 50/60Hz
Motor power consumption: 6. 5VA
Drive mode: power on, power off, close, spring automatic reset Running time: 18 seconds to open the valve, 7 seconds to close the valve
