Connection diameter: DN20 DN25 two-way
Connection method: internal thread G3/4″ G1″ (customizable NPT)
Media range: hot and cold water or 30% ethylene glycol solution 2℃ ~95℃
Valve body pressure: 2 · OMpa
Working voltage: AC24V/AC110V/AC220V 50/60Hz
Motor power consumption: 6. 5VA (motor power-off protection function when control is in place)
Drive mode: three-wire two-control (customizable three-wire one-control)
Operation time: 30 seconds to open the valve and 30 seconds to close the valve
