Connection diameter: DN15 DN20 DN25 DN32 two-way/three-way
Connection method: internal thread G1/2″ G3/4″ G1 ” 1 -1/4″ (customizable NPT)
Media range: hot and cold water or 30% ethylene glycol solution 2℃*95℃
Valve body pressure: 2. OMpa
Working voltage: AC24V/AC220V 50/60Hz
Motor power consumption: 6VA (motor power-off protection function when control is in place)
Drive mode: three-wire two-control (customized three-wire one-control)
Output torque: 4NM
Operation time: 15 seconds to open the valve and 15 seconds to close the valve (rotation angle ~9)
