Connection diameter: DN15DN65 two-way/three-way connection method: G thread internal thread (customizable NPT)
Media range: hot and cold water or 30% ethylene glycol solution 2℃~95℃
Flow characteristics: ~30% linear 30″100% equal percentage
Valve body pressure: 2 · OMpa /4. OMpa
Working voltage: AC24V/AC220V 50/60Hz
Motor power consumption: 6. 5VA (motor power-off protection function when control is in place)
Drive mode: three-wire two-control (three-wire valve)
Output torque: 16NM
Operation time: 90 seconds to open the valve and 90 seconds to close the valve (rotation angle ~9)
